Technical data
Lusuardi 80cc.
Engine No. 02-85-100
horizontal single-cylinder 2 stroke
liquid cooling
Bore 47.95
44mm stroke
79.41 displacement
Power 22 hp at 15000 rpm / tnin
rotary valve supply
Diagram 70 ° 115 °
Mikuni 34mm
Electronic ignition Motoplat battery powered
Primary gear
Final drive chain
multi-plate dry clutch
Transmission 6-speed extractable
Frame no DGM3568 1
Monocoque alluininio built-in tank
telescopic front suspension Marzocchi 30mm
Rear suspension. swingarm molybdenum tube box with Bitubo shock absorbers
220mm front disc brake with Brembo caliper
115mm rear disc brake with Brembo twin-piston caliper
Alloy wheels 18 ”
front tire 225 / l8
Pnewnatico rear 8 / 61-18
Dimensions (mm)
Wheelbase 1250
Weighs 56Kg Dry
Maximum speed 190Km / h
